Zw Group 3 Axle 40FT Skeleton Semi Trailer Container Skeleton Truck Semi Trailer for Mexico
- Overview
- Product Description
- Details Images
- Product Paramenters
- Company Profile
- Our Advantages
- Customer Photos
- Packing and Shipping
- FAQ
Basic Info.
| Model NO. | Skeleton Semi Trailer |
| Type | Semi-Trailer |
| Load Capacity | 30T |
| Certification | ECE, GCC, CE, ISO9001, DOT, CCC, ISO/TS16949 |
| Wheel Base | 9000-10000mm |
| Tread | 2240mm |
| Grade | Heavy Duty |
| Types of Suspension Systems | Air Suspension |
| Shape | Flatbed |
| Axle Number | 3 |
| Tire Number | 6 |
| Self-dumping | Not Self-dumping |
| ABS Anti-lock Braking System | No ABS Anti-lock Braking System |
| Material | Steel |
| Condition | New |
| Kingpin | 2" or 3.5" Traction Pin |
| Use | Truck Trailer |
| Size | 12500mm*2500mm*1550mm |
| Product Name | Skeleton Semi Truck Trailer |
| Landing Gear | Standard 28ton |
| Suspension | Common Mechanical |
| Painting | Optional |
| Capacity | 30t-60t |
| Axle Brand | Fuwa/BPW/Optional |
| Max Payload | 60t |
| Tire Specification | 12r22.5 Vacuum Tire /11.00r20 |
| Quantity of Axle | 2 or 3 |
| Transport Package | Nude |
| Specification | standard |
| Trademark | ZW-Trailer |
| Origin | Shandong, China |
| Production Capacity | 1000 Unit/Month |
Product Description
Product Description
Increase Efficiency and Profits: Why You Need a Skeleton Semi Trailer
The skeleton semi trailer, also known as a skeletal trailer, is a workhorse of the logistics industry. Here's why it should be your go-to trailer for maximizing your freight hauling operation:
Details Images
* Versatility: Skeleton trailers are designed to transport ISO shipping containers, the lifeblood of global trade. This means they can carry a wide variety of cargo, from dry goods and machinery to vehicles and even hazardous materials (with proper certification).* Efficiency: Skeleton trailers are lighter than enclosed trailers, which translates to better fuel economy for your truck. Additionally, their open design allows for faster loading and unloading times.* Multiple Size Options: These trailers come in various lengths, including the industry-standard 20ft, 40ft, and 45ft sizes, to accommodate your specific hauling needs.* Durability: Built with a strong steel frame, skeleton trailers are built to last and can withstand the demands of constant use.* Cost-effective: Compared to enclosed trailers, skeletons offer a lower initial investment and maintenance costs due to their simpler design.
Product Paramenters
| 20FT Skeleton Semi Trailer | 40FT Skeleton Semi Trailer | 45FT Skeleton Semi Trailer |
| Brand: Vehicle Master | Brand: Vehicle Master | Brand: Vehicle Master |
| 2 Axles/3 Axles | 3 Axles/ 4 Axles | 3 Axles/ 4 Axles |
| 20ft Container Loading | 1*40ft/2*20ft Container Loading | 1*45ft/1*40ft/2*20ft Container Loading |
| Loading Capacity: 20-50 Tons | Loading Capacity: 30-80 Tons | Loading Capacity: 30-80 Tons |
| Type: Gooseneck or Tandem | Type: Gooseneck or Tandem | Type: Gooseneck or Tandem |
| Main Bean | ||
| Material: Q345/T700 | Material: Q345/T700 | Material: T700 |
| Upper Plate Thickness: 12mm | Upper Plate Thickness: 14mm | Upper Plate Thickness: 10mm |
| Middle Plate Thickness: 6mm | Middle Plate Thickness: 6mm | Middle Plate Thickness: 5mm |
| Lower Plate Thickness: 12mm | Lower Plate Thickness: 16mm | Lower Plate Thickness: 10mm |
| Height: 500mm | Height: 500mm | Height: 420mm |
| Dimension | ||
| L*W*H: 7000mm*2480mm*1560mm | L*W*H: 12400mm*2480mm*1580mm | L*W*H: 13950mm*2500mm*1600mm |
| Axle | ||
| 2/3 Axles *13 Ton VEHCILE MASTER/FUWA/BPW | 3/4 Axles *13 Ton VEHCILE MASTER/FUWA/BPW | 3/4 Axles *13/16 Ton VEHCILE MASTER/FUWA/BPW |
| Tire | ||
| 12R22.5 (8/12 Pieces) Linglong/Triangle/Double Coin | 12R22.5 (12/16 Pieces) Linglong/Triangle/Double Coin | 12R22.5 (12/16 Pieces) Linglong/Triangle/Double Coin |
| Rim | ||
| 9.00*22.5 (8/12 Pieces) Steel/Aluminum | 9.0*22.5 (12/16 Pieces) Steel/Aluminum | 9.00*22.5 (12/16 Pieces) Steel/Aluminum |
| Leaf Spring | ||
| 90mm*13mm*10 Pieces 90mm*16mm*10 Pieces | 90mm*13mm*10 Pieces 90mm*16mm*10 Pieces | 90mm*13mm*10 Pieces 90mm*16mm*10 Pieces |
| King Pin | ||
| #50 (2")/#90 (3.5") JOST/Other Brand | #50 (2")/#90 (3.5") JOST/Other Brand | #50 (2")/#90 (3.5") JOST/Other Brand |
| Landing Gear | ||
| 28 Tons Two Speed JOST/Other Brand | 28 Tons Two Speed JOST/Other Brand | 28 Tons Two Speed JOST/Other Brand |
| Twist Lock | ||
| 4 Sets | 12 Sets | 12 Sets |
| Painting | ||
| Electrophoresis Painting | Electrophoresis Painting | Electrophoresis Painting |
Company Profile
Shandong Zhuowei International Trading Co., Ltd was established in 2000 specialized in manufacturing various trailers, such as container trailers,construction equipment transporting trailers, tractors, trailers spare parts, etc. with advanced automatic equipment and excellent quality control.
With the good quality and reputation, we have been authorized ISO,CCC,CE and B&V certificates by government. We have our own factory established in 2000 which is a professional manufacturer with 500 employees and 48,000,000 annual sales volume. Our products has been popular in South Asia, Middle East, Africa and South America.
Our Advantages
Customer Photos
Packing and Shipping
FAQ
1.Does your company has your own factory? Yes,we have a factory ourself,which is in this business for few years in China.Our factory is very famous where is manufacturing various trailers in Shan Dong,China.2.Can you satisfy my special requirement? Definitely!We can make the trailers based on your requirement.3.What's your minimum quantity? 1 set.4.How to trust us? The good faith management is our philosophy,and you are welcome to visit our company at any time.5.What's your payment term? We accpet both T/T and L/C T/T:30% deposit by T/T,70% balance should be paid before shipment. L/C:100% irrevocable Credit of Letter.
